COMPARE ALL MELANGERS
 SPECTRA 11 Melanger |  SPECTRA 25NB Melanger |  SPECTRA 45NB Melanger |  SPECTRA 70NB Melanger |  SPECTRA 105NB Melanger |  SPECTRA 155NB Melanger |
|---|---|---|---|---|---|
| Detachable Drum | Detachable Drum | Detachable Drum | Detachable Drum | Detachable Drum | Detachable Drum |
| Yes. Drum with contents can be removed from the machine and stored as is. | No. The Drum cannot be removed from the machine. But, the machine can be tilted and the contents poured out. Cleaning is very easy. Just add water and run the machine for a few seconds to self clean. Drum can be however removed for servicing or replacement. | No. The Drum cannot be removed from the machine. But, the machine can be tilted and the contents poured out. Cleaning is very easy. Just add water and run the machine for a few seconds to self clean. Drum can be however removed for servicing or replacement. | No. The Drum cannot be removed from the machine. But, the machine can be tilted and the contents poured out. Cleaning is very easy. Just add water and run the machine for a few seconds to self clean. Drum can be however removed for servicing or replacement. | No. The Drum cannot be removed from the machine. But, the machine can be tilted and the contents poured out. Cleaning is very easy. Just add water and run the machine for a few seconds to self clean. Drum can be however removed for servicing or replacement. | No. The Drum cannot be removed from the machine. But, the machine can be tilted and the contents poured out. Cleaning is very easy. Just add water and run the machine for a few seconds to self clean. Drum can be however removed for servicing or replacement. |
| Approximate Drum Volume | Approximate Drum Volume | Approximate Drum Volume | Approximate Drum Volume | Approximate Drum Volume | Approximate Drum Volume |
| 510 Cubic Inches (8 Litres) | 1020 Cubic Inches (17 Litres) | 2040 Cubic Inches (40 Litres) | 3300 Cubic Inches (55 Litres) | 4500 Cubic Inches (75 Litres) | 8100 Cubic inches (130 Litres) |
| Speed Controller | Speed Controller | Speed Controller | Speed Controller | Speed Controller | Speed Controller |
| Optionally Available | Yes. Comes Standard. | Yes. Comes Standard. | Yes. Comes Standard. | Yes. Comes Standard. | Yes. Comes Standard. |
| Drive | Drive | Drive | Drive | Drive | Drive |
| Rubber Belt | Chain Drive | Chain Drive | Chain Drive | Chain Drive | Chain Drive |
| Body | Body | Body | Body | Body | Body |
| ABS Plastic | SS 304 and steel | SS 304 and steel | SS 304 and steel | SS 304 and steel | SS 304 and steel |
| Size/Wt of roller stone | Size/Wt of roller stone | Size/Wt of roller stone | Size/Wt of roller stone | Size/Wt of roller stone | Size/Wt of roller stone |
| 1.5 kg each, 6 cm wide, 11 cm dia | 3.75 kg each, 7 cm wide, 15 cm dia | 10 kg each, 10 cm wide, 20 cm dia | 13 kg each, 10 cm wide, 23 cm dia | 18.5 kg each, 10 cm wide, 27.5 cm dia | 23.5 kg each, 11.5 cm wide, 31 cm dia |
| Empty drum weight without roller stones | Empty drum weight without roller stones | Empty drum weight without roller stones | Empty drum weight without roller stones | Empty drum weight without roller stones | Empty drum weight without roller stones |
| 6 lbs (3 Kg) approximately | Not Applicable | Not Applicable | Not Applicable | Not Applicable | Not Applicable |
| Approximate Dimensions | Approximate Dimensions | Approximate Dimensions | Approximate Dimensions | Approximate Dimensions | Approximate Dimensions |
| Length: 17 inches Width: 11 inches Height: 12 inches | Length: 26 inches Width: 16 inches Height: 24 inches | Length: 35 inches Width: 22 inches Height: 40 inches | Length: 35 inches Width: 22 inches Height: 42 inches | Length: 35 inches Width: 22 inches Height: 44 inches | Length: 43 inches Width: 24 inches Height: 52 inches |
| Drum lid | Drum lid | Drum lid | Drum lid | Drum lid | Drum lid |
| See through, Clear polycarbonate lid. Lid can be opened even while grinder is in operation. | Stainless Steel lid is not view through. Lid cannot be opened while grinder is in operation. But,simply turn down speed to zero and then you can open lid. | Stainless Steel lid is not view through. Lid cannot be opened while grinder is in operation. But,simply turn down speed to zero and then you can open lid. | Stainless Steel lid is not view through. Lid cannot be opened while grinder is in operation. But,simply turn down speed to zero and then you can open lid. | Stainless Steel lid is not view through. Lid cannot be opened while grinder is in operation. But,simply turn down speed to zero and then you can open lid. | Stainless Steel lid is not view through. Lid cannot be opened while grinder is in operation. But,simply turn down speed to zero and then you can open lid. |
| Approximate Electrical Specification | Approximate Electrical Specification | Approximate Electrical Specification | Approximate Electrical Specification | Approximate Electrical Specification | Approximate Electrical Specification |
| 1/6 HP 220-240V 50-60 Hz | 1/2 HP 220-240V 50-60 Hz | 2 HP 220-240V 50-60 Hz | 2 HP 220-240V 50-60 Hz | 2 HP 220-240V 50-60 Hz | 2 HP 220-240V 50-60 Hz |
| Approximate Weight of Machine | Approximate Weight of Machine | Approximate Weight of Machine | Approximate Weight of Machine | Approximate Weight of Machine | Approximate Weight of Machine |
| 18 kgs | 50 kgs | 135 kgs | 160 kgs | 180 kgs | 225 kgs |
| Approximate Weight and size with outer carton / Wooden Crate | Approximate Weight and size with outer carton / Wooden Crate | Approximate Weight and size with outer carton / Wooden Crate | Approximate Weight and size with outer carton / Wooden Crate | Approximate Weight and size with outer carton / Wooden Crate | Approximate Weight and size with outer carton / Wooden Crate |
| Without SpeedController: 19 kgs, 22 x 15 x 16 inches With Speed Controller: 28 kgs, 33 x 15 x 16 inches | 75 kgs 30 X 23 X 33 inches | 180 kgs 42 X 28 X 43 inches | 195 kgs 42 x 28 x 46 inches | 225 kgs 42 X 28 X 50 inches | 275 kgs 49 x 30 x 58 inches |
| Design Feature | Design Feature | Design Feature | Design Feature | Design Feature | Design Feature |
| For testing, trial and sampling applications. Compact to be kept on a table. Occupies minimum floor space. Ideal for home enthusiasts, laboratories etc. | Our largest machine. Sturdy and heavy duty. Tilting feature with Locking facility. Castor Wheels for convenience. Ideal for enterprises, laboratories etc. | Our largest machine. Sturdy and heavy duty. Tilting feature with Locking facility. Castor Wheels for convenience. Ideal for enterprises, laboratories etc. | Our largest machine. Sturdy and heavy duty. Tilting feature with Locking facility. Castor Wheels for convenience. Ideal for enterprises, laboratories etc. | Our largest machine. Sturdy and heavy duty. Tilting feature with Locking facility. Castor Wheels for convenience. Ideal for enterprises, laboratories etc. | Our largest machine. Sturdy and heavy duty. Tilting feature with Locking facility. Castor Wheels for convenience. Ideal for enterprises, laboratories etc. |
